StarTek FM220 is a UIDAI, STQC Certified Single fingerprint USB scanner. Startek FM20 issued for AADHAAR authentication. these scanner are is compliant with low image distortion. Startek fm220 gives fast scanning & matching speed. it is also provide choice to set different security levels for different application for/far demand, startek fm220 fingerprint scanner gives non-distorted image quality and small template size, real-life applications. service and device driver are provided by Barcode Bazar. support verification on various server platforms. StarTek FM220 for AADHAAR authentication. these scanner are is compliant with low image distortion. Startek fm220 gives fast scanning & matching speed. it's also provide choice to set different security levels for different application for/far demand, startek fm220 fingerprint scanner gives non-distorted image quality and small template size, real-life applications. service and device driver are provided by barcodebazar.Com support verification on various server platforms .
Features :
Product Details :
Screen Size | 1 |
Brand | Startek |
Model Name/Number | Fingerprint Scanner Startek Fm220u USB |
Specification :
Sensors | CMOS sensor |
Scanning | 1/15 second |
Image resolution | 500 dpi (H),500 dpi(V) (600dpi optional) |
Image capture format | 13.3 x 16.4(mm) (H * V) |
Scanner output image size | 264 * 324 pixels(H * V) |
Gray Level | 8bits/pixel, max 256 gray scales |
Image ratio of length to width | 1 : 1 |
Scanner interface cable | Standard USB compliant cable |
Power supply | 1 watt approx(from USB port) (200mA, approx, standby:60mA) |
Minimum hardware requirement | P3 800MHz CPU or up, 256MB, USB2.0 |
Dimension | 80mm (L) x 41mm(M) x 40mm(H) |
Weight | 100g(Approx) |
Distortion | <1% |
Temperature(without external enclosure) | 0 C - 50 Degree C |
Humidity | 90% non condensing |
Scanning light source | infrared red (940nm) |
Operating volts | +5V Tolerance 5% (USB connector) |
ESD | 15KV |
Compliance | CE, FCC |
